PT5506N

Enlarger

Lmages are for reference only See Product Specitications

Texas Instruments PT5506N

Manufacturer :
Texas Instruments
Mfr. Part # :
PT5506N
Description
DC DC CONVERTER 1.2V
Catalog
DC DC Converters
Lead Free Status / RoHS Status
Contains lead / RoHS non-compliant
DataSheet
PT5506N PDF
In Stock
463
PT5506N Tech Specifications
SeriesExcalibur™ PT5500
PackageTray
Part StatusObsolete
TypeNon-Isolated PoL Module
Number of Outputs1
Voltage - Input (Min)3.1V
Voltage - Input (Max)5.5V
Voltage - Output 11.2V
Voltage - Output 2-
Voltage - Output 3-
Voltage - Output 4-
Current - Output (Max)3A
Power (Watts)-
Voltage - Isolation-
ApplicationsITE (Commercial)
Features-
Operating Temperature-40°C ~ 85°C
Efficiency79%
Mounting TypeThrough Hole
Package / Case5-SIP Module
Size / Dimension0.90" L x 0.48" W x 0.95" H (22.9mm x 12.2mm x 24.1mm)
Supplier Device Package-
Control Features-
Approval Agency-
Standard Number-
Request Quote Now
Request Quote Now

We can supply PT5506N, use the request quote form to request PT5506N pirce and lead time. IKeyParts.com a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PT5506N. The price and lead time for PT5506N depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# PT5506N. We look forward to working with you to establish long-term relations of cooperation.
