2SD1683S

Enlarger

Lmages are for reference only See Product Specitications

Sanyo Semiconductor/ON Semiconductor 2SD1683S

Manufacturer :
Sanyo Semiconductor/ON Semiconductor
Mfr. Part # :
2SD1683S
Description
TRANS NPN 50V 4A TO-126ML
Catalog
Transistors - Bipolar (BJT) - Single
Lead Free Status / RoHS Status
Contains lead / RoHS non-compliant
DataSheet
2SD1683S PDF
In Stock
509
2SD1683S Tech Specifications
Series-
PackageBulk
Part StatusObsolete
Transistor TypeNPN
Current - Collector (Ic) (Max)4 A
Voltage - Collector Emitter Breakdown (Max)50 V
Vce Saturation (Max) @ Ib, Ic500mV @ 100mA, 2A
Current - Collector Cutoff (Max)1µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce100 @ 100mA, 2V
Power - Max1.5 W
Frequency - Transition150MHz
Operating Temperature150°C (TJ)
Mounting TypeThrough Hole
Package / CaseTO-225AA, TO-126-3
Supplier Device PackageTO-126ML
Request Quote Now
Request Quote Now

We can supply 2SD1683S, use the request quote form to request 2SD1683S pirce and lead time. IKeyParts.com a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 2SD1683S. The price and lead time for 2SD1683S depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# 2SD1683S. We look forward to working with you to establish long-term relations of cooperation.
