IXFV15N100P

Enlarger

Lmages are for reference only See Product Specitications

Wickmann / Littelfuse IXFV15N100P

Manufacturer :
Wickmann / Littelfuse
Mfr. Part # :
IXFV15N100P
Description
MOSFET N-CH 1000V 15A PLUS220
Catalog
Transistors - FETs, MOSFETs - Single
Lead Free Status / RoHS Status
Contains lead / RoHS non-compliant
DataSheet
IXFV15N100P PDF
In Stock
421
IXFV15N100P Tech Specifications
SeriesHiPerFET™, PolarP2™
PackageTube
Part StatusObsolete
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)1000 V
Current - Continuous Drain (Id) @ 25°C15A (Tc)
Drive Voltage (Max Rds On, Min Rds On)10V
Rds On (Max) @ Id, Vgs760mOhm @ 500mA, 10V
Vgs(th) (Max) @ Id6.5V @ 1mA
Gate Charge (Qg) (Max) @ Vgs97 nC @ 10 V
Vgs (Max)±30V
Input Capacitance (Ciss) (Max) @ Vds5140 pF @ 25 V
FET Feature-
Power Dissipation (Max)543W (Tc)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeThrough Hole
Supplier Device PackagePLUS220
Package / CaseTO-220-3, Short Tab
Request Quote Now
Request Quote Now

We can supply IXFV15N100P, use the request quote form to request IXFV15N100P pirce and lead time. IKeyParts.com a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IXFV15N100P. The price and lead time for IXFV15N100P depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# IXFV15N100P. We look forward to working with you to establish long-term relations of cooperation.
