PM25L-075-035

Enlarger

Lmages are for reference only See Product Specitications

Lin Engineering PM25L-075-035

Manufacturer :
Lin Engineering
Mfr. Part # :
PM25L-075-035
Description
PERMANENT MAGNET STEPPER MOTOR
Catalog
Stepper Motors
Lead Free Status / RoHS Status
Contains lead / RoHS non-compliant
DataSheet
PM25L-075-035 PDF
PM25L-075-035 Tech Specifications
SeriesPM
PackageTray
Part StatusActive
Type-
Coil TypeBipolar
Voltage - Rated12VDC
Current Rating (Amps)0.35 A
Steps per Revolution48
Step Angle7.5°
Accuracy-
Torque - Holding (oz-in / mNm)3.7 / 26
Size / DimensionRound - 0.984" Dia (25.00mm)
NEMA Frame Size-
Diameter - Shaft0.079" (2.00mm)
Length - Shaft and Bearing0.394" (10.00mm)
Mounting Hole Spacing1.260" (32.00mm)
Termination StyleWire Leads with Connector
Operating Temperature-20°C ~ 50°C
Coil Resistance14 Ohms
FeaturesRound Shaft
Request Quote Now
Request Quote Now

We can supply PM25L-075-035, use the request quote form to request PM25L-075-035 pirce and lead time. IKeyParts.com a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PM25L-075-035. The price and lead time for PM25L-075-035 depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# PM25L-075-035. We look forward to working with you to establish long-term relations of cooperation.
