PM20S-180-021

Enlarger

Lmages are for reference only See Product Specitications

Lin Engineering PM20S-180-021

Manufacturer :
Lin Engineering
Mfr. Part # :
PM20S-180-021
Description
PERMANENT MAGNET STEPPER MOTOR
Catalog
Stepper Motors
Lead Free Status / RoHS Status
Contains lead / RoHS non-compliant
DataSheet
PM20S-180-021 PDF
PM20S-180-021 Tech Specifications
Series-
PackageTray
Part StatusActive
Type-
Coil TypeBipolar
Voltage - Rated12VDC
Current Rating (Amps)0.21 A
Steps per Revolution20
Step Angle18°
Accuracy-
Torque - Holding (oz-in / mNm)1.18 / 8.34
Size / DimensionRound - 0.787" Dia (20.00mm)
NEMA Frame Size-
Diameter - Shaft0.059" (1.50mm)
Length - Shaft and Bearing0.394" (10.00mm)
Mounting Hole Spacing0.984" (25.00mm)
Termination StyleWire Leads with Connector
Operating Temperature-20°C ~ 50°C
Coil Resistance25 Ohms
FeaturesRound Shaft
Request Quote Now
Request Quote Now

We can supply PM20S-180-021, use the request quote form to request PM20S-180-021 pirce and lead time. IKeyParts.com a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PM20S-180-021. The price and lead time for PM20S-180-021 depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# PM20S-180-021. We look forward to working with you to establish long-term relations of cooperation.
