TNPW0603109KDHEA

Enlarger

Lmages are for reference only See Product Specitications

Vishay / Dale TNPW0603109KDHEA

Manufacturer :
Vishay / Dale
Mfr. Part # :
TNPW0603109KDHEA
Description
RES 109K OHM 0.5% 1/8W 0603
Catalog
Chip Resistors-Surface Mount
Lead Free Status / RoHS Status
Contains lead / RoHS non-compliant
DataSheet
TNPW0603109KDHEA PDF
In Stock
744
TNPW0603109KDHEA Tech Specifications
SeriesTNPW e3
PackageTape & Reel (TR)
Part StatusActive
Resistance109 kOhms
Tolerance±0.5%
Power (Watts)0.125W, 1/8W
CompositionThin Film
FeaturesAnti-Sulfur, Automotive AEC-Q200, Moisture Resistant
Temperature Coefficient±50ppm/°C
Operating Temperature-55°C ~ 155°C
Package / Case0603 (1608 Metric)
Supplier Device Package0603
RatingsAEC-Q200
Size / Dimension0.061" L x 0.033" W (1.55mm x 0.85mm)
Height - Seated (Max)0.022" (0.55mm)
Number of Terminations2
Failure Rate-
Request Quote Now
Request Quote Now

We can supply TNPW0603109KDHEA, use the request quote form to request TNPW0603109KDHEA pirce and lead time. IKeyParts.com a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TNPW0603109KDHEA. The price and lead time for TNPW0603109KDHEA depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# TNPW0603109KDHEA. We look forward to working with you to establish long-term relations of cooperation.
