Series | - | |
Package | Tube | |
Part Status | Active | |
FET Type | 2 N Channel (Phase Leg) | |
FET Feature | Silicon Carbide (SiC) | |
Drain to Source Voltage (Vdss) | 1200V (1.2kV) | |
Current - Continuous Drain (Id) @ 25°C | 173A (Tc) | |
Rds On (Max) @ Id, Vgs | 16mOhm @ 80A, 20V | |
Vgs(th) (Max) @ Id | 2.8V @ 2mA | |
Gate Charge (Qg) (Max) @ Vgs | 464nC @ 20V | |
Input Capacitance (Ciss) (Max) @ Vds | 6040pF @ 1000V | |
Power - Max | 745W (Tc) | |
Operating Temperature | -40°C ~ 175°C (TJ) | |
Mounting Type | Chassis Mount | |
Package / Case | Module | |
Supplier Device Package | SP1F |
We can supply MSCSM120AM16CT1AG, use the request quote form to request MSCSM120AM16CT1AG pirce and lead time. IKeyParts.com a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MSCSM120AM16CT1AG. The price and lead time for MSCSM120AM16CT1AG depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# MSCSM120AM16CT1AG. We look forward to working with you to establish long-term relations of cooperation.
![]() |
