Series | - | |
Package | Bulk | |
Part Status | Active | |
Structure | Bridge, Single Phase - SCRs/Diodes (Layout 2) | |
Number of SCRs, Diodes | 2 SCRs, 2 Diodes | |
Voltage - Off State | 600 V | |
Current - On State (It (AV)) (Max) | - | |
Current - On State (It (RMS)) (Max) | - | |
Voltage - Gate Trigger (Vgt) (Max) | 3 V | |
Current - Gate Trigger (Igt) (Max) | 100 mA | |
Current - Non Rep. Surge 50, 60Hz (Itsm) | 300A @ 60Hz | |
Current - Hold (Ih) (Max) | - | |
Operating Temperature | -40°C ~ 125°C (TJ) | |
Mounting Type | Through Hole | |
Package / Case | Module |
We can supply L522F, use the request quote form to request L522F pirce and lead time. IKeyParts.com a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number L522F. The price and lead time for L522F depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# L522F. We look forward to working with you to establish long-term relations of cooperation.
![]() |
