566AXZ6R3M

Enlarger

Lmages are for reference only See Product Specitications

Cornell Dubilier Electronics 566AXZ6R3M

Manufacturer :
Cornell Dubilier Electronics
Mfr. Part # :
566AXZ6R3M
Description
CAP ALUM 56UF 20% 6.3V SMD
Catalog
Aluminum Electrolytic Capacitors
Lead Free Status / RoHS Status
Contains lead / RoHS non-compliant
DataSheet
566AXZ6R3M PDF
566AXZ6R3M Tech Specifications
SeriesAXZ
PackageBulk
Part StatusActive
Capacitance56 µF
Tolerance±20%
Voltage - Rated6.3 V
ESR (Equivalent Series Resistance)7.11Ohm @ 120Hz
Lifetime @ Temp.2000 Hrs @ 105°C
Operating Temperature-55°C ~ 105°C
PolarizationPolar
Ratings-
ApplicationsGeneral Purpose
Ripple Current @ Low Frequency75 mA @ 120 Hz
Ripple Current @ High Frequency150 mA @ 100 kHz
Impedance760 mOhms
Lead Spacing-
Size / Dimension0.197" Dia (5.00mm)
Height - Seated (Max)0.217" (5.50mm)
Surface Mount Land Size0.209" L x 0.209" W (5.30mm x 5.30mm)
Mounting TypeSurface Mount
Package / CaseRadial, Can - SMD
Request Quote Now
Request Quote Now

We can supply 566AXZ6R3M, use the request quote form to request 566AXZ6R3M pirce and lead time. IKeyParts.com a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 566AXZ6R3M. The price and lead time for 566AXZ6R3M depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# 566AXZ6R3M. We look forward to working with you to establish long-term relations of cooperation.
