LM109K

Enlarger

Lmages are for reference only See Product Specitications

Texas Instruments LM109K

Manufacturer :
Texas Instruments
Mfr. Part # :
LM109K
Description
IC REG LINEAR 5.05V 1A TO3-2
Catalog
PMIC - Voltage Regulators - Linear
Lead Free Status / RoHS Status
Contains lead / RoHS non-compliant
DataSheet
LM109K PDF
LM109K Tech Specifications
Series-
PackageTube
Part StatusActive
Output ConfigurationPositive
Output TypeFixed
Number of Regulators1
Voltage - Input (Max)25V
Voltage - Output (Min/Fixed)5.05V
Voltage - Output (Max)-
Voltage Dropout (Max)-
Current - Output1A
Current - Quiescent (Iq)5.2 mA
Current - Supply (Max)10 mA
PSRR-
Control Features-
Protection FeaturesOver Current, Over Temperature
Operating Temperature-55°C ~ 150°C
Mounting TypeThrough Hole
Package / CaseTO-204AA, TO-3
Supplier Device PackageTO-3-2
Request Quote Now
Request Quote Now

We can supply LM109K, use the request quote form to request LM109K pirce and lead time. IKeyParts.com a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number LM109K. The price and lead time for LM109K depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# LM109K. We look forward to working with you to establish long-term relations of cooperation.
